Here is how to check the fuel sender and guage; You need to check the Pink and Pink/Black wire coming out of the baffle tube in the gas tank. The sending unit works off resistance. Pull the plug apart at the tank, and use an ohm meter to check for resistance between the two pink wires.

  1. Seadoo Fuel Gauge Manual Download
  2. Seadoo Manuals 2011

Paul Martin of Arnold, Missouri got a wicked deal when he bought his used SeaDoo. But when he took it out for the first time on the lake, the fuel sensor didn’t appear to be working. The previous owner claimed the fuel sensor worked when he had it and so Paul was faced with getting the fuel sensor replaced, repaired or fixing it himself. Fortunately, Paul likes to take things apart but before he did he came to Jet Ski Plus for some advice. Here’s what we shared with Paul about testing his SeaDoo’s fuel sending unit.

Inside your SeaDoo’s fuel tank is a plastic tube known as the fuel pickup, and within this tube is an integrated fuel sending unit. The sending unit is made up of a long narrow circuit board with 9-12 Reed switches and several resistors. These Reed switches and resistors are wired so that the total resistance across the circuit board increases as each Reed switch closes from the bottom of the tank to the top. Regardless of the model and year of your SeaDoo, the resistance ranges from 90 to 0 Ohms, with 90 Ohms representing an empty tank and 0 Ohms representing a full tank. These Reed switches are activated by a magnet attached to a float that rides up and down internal rails with the fuel level.

While the design is simple, the weak link in the system is a one-time fuse on the fuel sending unit’s circuit board. Once the fuse blows, the sending unit is rendered non-functional since the fuse can’t be replaced. Here are the steps we recommend for testing the fuel sending unit for 2-stroke carbureted SeaDoos. Unfortunately, these steps won’t work on fuel injected or 4-TEC SeaDoos.

  1. Aug 31, 2020 for sale three jet skis.1. 2001 seadoo gtx - di (direct fuel injection) about 80 hr on engine and 270 on ski, runs great, just installed new impeller and liner, this ski is ready to go. 2001 seadoo gtx-di (direct fuel injection) this ski only has 71 hr on it, it runs just has a miss that need to be fixed. 2002 kawasaki stx.
  2. A simpler peace of mind solution is to purchase about a foot of fuel line and a clear fuel filter from an auto parts store and install as close to the carb(s) as possible. That way if you get any grey line deterioration, the filter will catch it before it gets to the small internal Mikuni filters and causes a lean condition.

This quick and easy test will help you diagnose most common problems with the fuel sending unit and doesn’t require you to remove the fuel baffle from the tank. All you need is an Ohmmeter and some time.

  1. First, you’ll want to locate the fuel sending unit and sending wires. Potted into the side of the fuel sending unit, the wires are pink and pink/black. Follow these wires until you come to the inline 2-wire connector and then disconnect the connector.
  2. With the connector disconnected, you’re ready to perform a resistance test on the fuel sending unit. This is accomplished by connecting the Ohmmeter to the pink and pink/black wire terminals running to the fuel sending unit.
  3. With the Ohmmeter connected, you’ll want to record the resistance and approximate level of the fuel in the tank.
  4. Next, compare your readings with the following that are typical on a good sending unit:
1993 seadoo manual
  • 0-5 Ohms (Full Tank)
  • 45+/- Ohms (Half Full Tank)
  • 85-95 Ohms (Empty Tank)

Seadoo Fuel Gauge Manual Download

If your Ohmmeter shows an open circuit or infinite resistance, the internal fuse is blown and the sending unit will need to be replaced.

Seadoo

If your ohmmeter reads 85-95 Ohms and the tank obviously has gas, either the float has lost its buoyancy or the magnet has come loose from the float. If either is the case, your fuel gauge would always show an empty tank of gas. In this case, you’ll need to install a new float into the sending unit.

If your fuel gauge seems to be stuck or show the same reading, the float could be wedged inside the plastic tube. Though rare, we have encountered instances where the upper metal hose clamp is so tight that it pinches the fuel sending unit and wedges the float in place.

Seadoo Manuals 2011

Certainly there are other potential failures but overall, these scenarios account for close to 90% of the reasons why fuel sending units fail.
